Diesel Belting Micro-V serpentine belt, J section, 22 ribs (2.024in wide), 52.0in outside circumference. EPDM construction with polyester tensile cords for high-flexibility, multi-groove power transmission drives.

Key Specifications

• Belt Type: Micro-V Belt
• Section/Profile: J
• Width: 2.024 in
• Rib Count: 22
• Outside Circumference: 52.0 in
• Material: EPDM
• Reinforcement: Polyester Cord
• Brand: Diesel Belting
• Part Number: 520J22

Common Applications

• Serpentine accessory drives
• HVAC blower and fan drives
• Appliance motors
• Fitness and office equipment
• Compact high-ratio drives

Notes

• Manufactured to RMA dimensional tolerances for the specified cross-section.
• Match belt section and length to sheave groove profile. Confirm outside circumference against your existing belt or catalog data.

Need Help Selecting?

Working from pulley diameters and center distance? This product is indexed for our belt sizing tool—enter your drive dimensions and find the correct belt for your application. Contact Texas Belting & Supply for engineering assistance on any drive design question.
